FEATURES, FUNCTIONS AND SPECIFICATIONS:
• 40 channels AM / FM
• Up/down channel selector
• Volume adjustment and ON/OFF
• Manual squelch and ASC
• Multi-functions LCD display
• Frequencies display
• S-meter
• ANL, NB, HI-CUT filters
• Scan
• F function key
• Beep Function
• Roger Beep
• Mode switch AM / FM
• Dual watch
• Tone
• CTCSS / DCS
• Key locking
• Preset channel programmable (EMG 1 & 2)
• Eco mode
• External microphone plug
• External loudspeaker jack
• Flashlight
• Battery : Lithium-Ion

General
• Number of channels: 40
• Modulation modes: AM/FM
• Frequency ranges: from 26,965 MHz to 27,405 MHz
• CTCSS: 38 tones
• DCS: 104 codes
• Antenna impedance: 50 ohms
• Power supply:
…7.4 V (Handheld configuration)
…13.2 V (Mobile configuration)
• Size: 152 (H) x 66,5 (L) x 37 (P) mm
• Weight: 305 gram with battery
• Loud speaker: 8 ohms, 1 W

Transmission
• Frequency allowance: +/- 200 Hz
• Carrier power: 4 W AM / 4 W FM
• Transmission interference: inferior to 4 nW (- 54 dBm)
• Audio response: 300 Hz to 3 KHz
• Emitted power in the adj. channel: inferior to 20 μW
• Microphone sensitivity: 7 mV
• Drain: 1,8 A max.
• Modulated signal distortion: 2 %

Reception
• Maxi. sensitivity at 20 dB sinad:
…0.5 μV – 113 dBm AM
…0.35 μV – 116 dBm FM
• Frequency response: 300 Hz to 3 kHz
• Adjacent channel selectivity: 60 dB
• Maximum audio power: 1 W
• Squelch sensitivity:
…min. 0,2 μV – 120 dBm
..max. 1 mV – 47 dBm
• Frequency image rejection rate: 60 dB
• Intermediate frequency rej. rate: 70 dB
• Drain: Mode ECO

PACKING INCLUDES:
1 Pc of Transceiver
1 pc of Belt Clip
1 Pc of Antenna
1 Pc of AC Adapter
1 Pc of CLP Power cable
1 Pc of Wrist Strap
1 Pc of Microphone holder
1 Pc of User Manual in English and Polish
1 Pc of User Manual in French and Spanish
